Key Features and Functions
Fast spectrum analysis covering frequency 9 kHz to 3 GHz
0.5 dB overall amplitude accuracy
Efficient AM/FM, ASK/FSK demodulation analysis suites for IoT transmitter characterization
3 GHz tracking generator provides stimulus response measurement for component characterization
Automation and communication interface with industry standard SCPI language support and USB/GPIB/LAN connectivity choices
Ideal for R&D, low cost manufacturing, and RF education
High qulity with low cost
For more details: View Data Sheet
| Frequency | 9 kHz to 3 GHz |
|---|---|
| Standard Attenuator Range | 70 dB |
| Standard Attenuator Step | 1 dB |
| DANL @1 GHz | -145 dBm |
| Maximum Analysis Bandwidth | 1 MHz |
| Phase Noise @1 GHz (1 MHz offset) | -112 dBc/Hz |
| Phase Noise @1 GHz (30 kHz offset) | n/a |
| TOI @1 GHz (3rd Order Intercept) | +13 dBm |
| Applications Available | No |
| Overall Amplitude Accuracy | ±0.5 dB |
| Bandwidth Options | 1 MHz |
| Performance Level | ◆◇◇◇◇◇ |
| Applications-Cellular | n/a |
| Applications-General Purpose |
|
| Applications-Wireless Connectivity |
|
| Triggering |
|
